Description
- Maxwell proprietary gearbox – custom ratio for optimised performance, direct fit to larger diameter shafts, large bearings & seals, robust design.
- Proven Maxwell 1000W motor as used on the popular RC Series and VWC/HWC models.
- Large diameter high strength shaft – higher holding load and improved resistance to bending.
- Marine anodised aluminium legs to increase the life of aluminium hulls.
- Large diameter plain bearings for a longer life, stronger and more robust in the harsh marine environment.
- Gearbox bearings are lubricated sintered bronze. Non gearbox end is self‑lubricated composite bearing for minimal maintenance.
- MAX Warp – optimised rope construction for maximum hold with enough stretch to minimise impact loads when anchored.
- Engineered mounting design, optimised for strength, compact dimensions through integration with gearbox.
| Model | 8-6 |
| Electric motor | DC Motor |
| Motor power | 1000W |
| Voltage | 12V or 24V |
| Max pulling force (1 layer on drum) | 1000kg |
| Max pulling force (full drum) | 350kg |
| Haulage speed (full drum) | 60m/min |
| Haulage speed (1 layer on drum) | 13m/min |
| Rope size | 6mm MAX Warp x 150m |
| Chain size | 6mm Short Link DIN766 x10m |
| Net Weight (Incl rope/chain) | 31kg |
| Note: Included: Solenoid, Circuit Breaker, Up/Down Switch | |
