Description
Powerful trimming systems made for extreme conditions
Items included in sets
- Electronic Indicator Control with internal sensors – no wires or cables exposed to the harsh marine environment
- Automatic Tab Retractor (ATR) automatically retracts the tabs to the full-up position when ignition is turned off
- Two Compact Dual Acting Hydraulic Power Units, each producing about 1,100 kg (2,400 pounds) of force through two actuators
- Stainless Steel Actuators: dual acting (with no external hydraulic lines); precision machined, single or dual cylinder; no dissimilar metals; XPT actuator overall length is 12 inches
- Heavy Duty Trim Planes: Laser-cut 7-gauge (4.7 mm), Stainless Steel
- Trim Tabs can be customized. Please contact Exalto Emirates for customized quote
Note: 24V version available on request
| Part number (12V) | Model | Trim tab size span x chord (in) | Boat length (ft.) |
| 06.11.0109 | XPT1218EIC | 12” x 18” | 28’ – 35’ |
| 06.11.0107 | XPT1520EIC | 15” x 20” | 35’ – 45’ |
| 06.11.0113 | XPT1824EIC | 18” x 24” | 50’ – 60’ |
Additional information
| OEM |
|---|
